APPLICATION:
NY approved housing. Ideal for commercial and industrial facilities. LED Steel series utilizes a unique illumination design.

FEATURES:
- NY approved housing, durable and white power coated 20-gauge steel construction. Energy efficient LED, heavy duty steel housing with universal mounting kit.
- NY approved exit letters 8” height.
- Removable snap-out knockouts and chevron directional arrows.
- Single face configuration.
- 90+ minute emergency operation.
- Available in white or black housing.

MOUNTING:
- Wall mounting.
- Wall mounting directly to standard J-Box, mounting hardware provided.

ELECTRICAL:
- 120/277V dual voltage operation standard.
- Charge rate and power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.

LAMPS:
- Standard with three(3) 12 watts fully adjustable, glare-free incandescent lighting heads. High-performance smooth thermoplastic reflector and tempered glass lens for optimal light distribution.

BATTERY:
- Maintenance-free and 6V 10Ah rechargeable sealed lead acid battery on emergency (EM) units.
- Fully automatic solid-state, two-rate charger initiates battery charging to recharge a discharged battery in 24 hours.
- Internal solid-state transfer switch automatically connects the internal battery to LEDs for minimum 90 minute emergency illumination.
- LVD (Low Voltage Disconnection) prevents battery from deep discharge.

LISTING:
- 5 years limited warranty on materials and all electronics. Battery pro-rated for two years.
- LED lamps are 25 years limited warranty.
- UL listed for damp locations (20°C – 50°C).
- Meets UL924, National Electrical Code, NFPA 70, NFPA 101 and the Life Safety Code, NEC, OSHA, Local and State Codes.
