APPLICATION:
The full-cutoff polycarbonate optical lens with UV stabilizers lens LED wall pack is ideal for security, pathway and perimeter lighting, and building entryways and walkways.

FEATURES:
- Sealed die-casting profile for indoor and outdoor.
- Housing with 3 pieces of 1/2” threaded hole for easier wire connections.
- Dark bronze finish is standard.
- Operating temperature: -40ºF (-40ºC) to 104ºF (40ºC)

MOUNTING:
- Wall mounting only.
- Suitable for junction box mounting and surface mounting.

COVER:
- Polycarbonate clear optical lens with UV stabilizers prevent from yellowing and deformation.

LED:
- Lumileds 3030 LED chips.
- Color temperature: 4000 / 5000K
- Lumen efficiency: ≥ 110 lm/W
- Color rendering index: >70
- Life span: 50,000 hrs

ELECTRICAL:
- Input voltage: 120-277Vac., 50/60Hz
- Operating temperature: -22ºF (-30ºC) to 113ºF (45ºC)
- Surge protection: Line-Line 1kV, Line-Earch 2kV
- Optional photocell.
- UL 1310 listed.

LISTING:
- UL / cUL listed.
- DLC listed.
- Suitable for wet location.
- 5 years limited warranty.
