APPLICATION:
Ideal for location of retail stores, warehouses, storage, gymnasiums areas and general open areas.  Suited for medium to high mount heights of 20’ or lower.

FEATURES:
- Heavy duty die-cast aluminum ballast housing with a white polyester powder paint finish.
- Easy to change out with other reflectors replace or remove and bottom lens.

MOUNTING:
- Steel hanger comes as standard.
- Comes with steel hook or die cast hook for easy mounting (WHK).
- Pendant splice box threaded for 3/4” conduit or hook mount.

REFLECTOR & BOTTOM LENS:
- High impact, UV-stabilized prismatic polycarbonate reflector and lens. Anodized aluminum reflector.
- Available with conical bottom lens, drop  bottom lens and heat and impact resistant tempered clear glass flat lens in options. Except 19” without bottom lens.

LAMP:
- Circular induction lamp.
- Color temperature : 5000K standard.
- 100,000 hours, long lamp life rating, nominal 82Lm/W, 80+ CRI.
- Lamp included.

ELECTRICAL:
- High power factor(≥ 95%), instant start, high frequency energy, from the electronic ballast (generator); High-frequency power to the discharge vessel (lamp) to initiate and maintain a gas discharge for a rated 100,000 hours of life.
- Low start-up temperature, closed fixture for ambient temperatures range is from -25°C to 50°C; Higher ambient temperatures may reduce lamp life.
- Input voltage: 120-277V.
- Input frequency: 50/60Hz.

LISTING:
- UL/CUL listed.
- Suitable for damp location.
- Limited 10 years warranty on induction system (including material & workmanship).
- ARRA compliant (optional).
