APPLICATION:
Up light and down light with divider for hospital bed light.  Acrylic diffuser with metal end caps. Ideal for use in bed light, nursing home light, task light and stairwells areas.

FEATURES:
- High-gloss baked enamel finish over rust inhibiting phosphate coat on die formed cold rolled steel housing. Post powder coated white, black and bare finish.
- Clear prismatic acrylic with ribbed front diffuser; optional clear ribbed up light acrylic diffuser.
- Up light fixture with divider and up light acrylic. Dividers are available for up light and/or down light; four-position pull-switch.
- Emergency battery backup with test switch and indicator light. (4ft only)
- Optional rocker switch, grounded convenience outlet and GFCI.
- Custom modifications to physical specifications and color are available for this fixture.
- Wall mounted.

LED:
- High quality array LEDs.
- LM80
- Color Temperature: 3000/3500/4000/5000 (K)
- Color Rendering Index: > 80 Ra.
- 50,000 hours.

ELECTRICAL:
- High power factor electronic driver, operate from a 120 ~ 277 Vac input range, 50 / 60 Hz.
- Features included over voltage protection, surge, short circuit protection and over load protection.
- Power Factor: typical > 0.95, THD < 20, meets Class1 or Class 2 circuit.
- 0-10V dimmable driver as standard.
- 0-10VDC dimming 10-100%(STD), 1-100%(DM1).
- Minimum starting temperature: -4°F (-20°C) ~ 122°F (50°C).

LISTING:
- UL/CUL listed and labeled.
- Suitable for damp locations.
- CEC Compliant EM (please contact for more information).
- Made in USA.
- ARRA compliant.
- 7 or 10 years limited warranty. (optional)
