APPLICATION:
This retrofit solution, in which the same bases as classic fluorescent lamps. LED T8 tube is alternative to T8 fluorescent lamps, for existing lighting installations with regular T8 fluorescent lamps. No changes to the luminaires are required, just easily replace them with energy-efficient and long-lasting LED lamps with one simple twist. The next generation with long life, low energy consumption and no mercury.

FEATURES:
- T8 Universal LED tube (compatible with and without AC ballast)
- LED T8 tube has a unique high efficiency heat sink design.
- LED tube alternatives to classic T8 fluorescent lamps replacement, simple re-wire, replacement allows for quick installation.
- High lighting transmittance cover, no darkness and flicker.
- Lamp base : Medium Bi-Pin base (G13)
- Beam angle : 160°
- Color rendering index : 80+ CRI
- Operating temperature range : -5°F(-20°C) ~ 105°F(40°C)
- Low maintenance requirements, life of up to 50,000 hours.
- Use for indoor.

ELECTRICAL:
- Input voltage: 100-277Vac, 50/60 Hz
- Power factor : > 0.90
- Single end AC power input(100-277V).
- Double end power with electronic instant start ballast.
- Ballast brand: Philip Advance, GE, Osram, Sylvania, Fullham.

INSTALLATIONS:
AC Direct
- Remove the existing fluorescent lamp.
- Remove / bypass the existing T8 or T12 ballast.
- Non-shunted Medium Bi-Pin fluorescent lamp holders required.
- Install the new LED Tube.

Plug & Play
- Remove the existing fluorescent lamp.
- Install the new LED Tube.
- Compatible with instant start electronic ballasts only.
- Does not compatible with Rapid start ballast.

LISTING:
- UL Listed for Retrofit Application.
- LM80 Certification.
- DLC listed.
- LM79.
- RoHS compliant.
- 5 years limited warranty.
