APPLICATION:
Heavy duty die-cast aluminum housing. Modular design LED and aluminum reflector allows for ease of maintenance.  Use on building facades, walkways, drive ways, tennis courts, parking lots, commercial and industrial complexes. As well as general safety and security lighting.

FEATURES:
- Heavy duty die-cast aluminum housing and door frame. Housing is dark bronze polyester powder paint finish standard. Also available in white, black and custom color finish.
- Silicone rubber gasket included to prevent dirt or moisture from outside.
- Heat and impact resistant tempered clear glass lens.

MOUNTING:
- Provided with a standard heavy-duty TR (yoke) mount for both ground and wall mount. Optional SF (slip fitter) mount, WTR (wide yoke mount). Wall mount bracket available.

LED:
- High efficient LED modules, components are products of Samsung LEDs. (G2LED : Cree LED)
- High safety with complete waterproof and thermal emission of LED Module. IP67 rated
- 5000K color temperature standard.
- Color Rendering Index: 82+ Ra.
- Luminous Efficacy: 125 LM/W
- Input Voltage: 24Vdc
- 60°/120° Beam Angle.
- 50,000 hours.

ELECTRICAL:
- High power factor electronic driver, operate from a 90 ~ 305 Vac input range, 50 / 60 Hz.
- Features include over voltage protection, surge, short circuit protection and over load protection.
- Waterproof (IP67) and damp location.
- All-Round Protection: OVP, SCP, OTP.
- Class 2 and SELV
- Power Factor: typical > 0.92
- Optional 1-10V dimmable driver. (Dimmer supplied by others)
- Minimum starting temperature: -22°F (-30°C) ~ 122°F (50°C).
- UL8750, UL1012, UL1310 Class 2, CSA-C22.2 No. 107.1, CSA C22.2 NO. 223-M91 Class 2

LISTING:
- UL/ CUL listed.
- RoHS.
- IP67 rated.
- Tested to IESNA LM80 standards.
- Suitable for wet locations.
- 5 years limited warranty.
- ARRA compliant.
