APPLICATION:
Large flood light design for walkways, parking lots, street lighting and drive ways.  For other general applications where flood lighting may come into use.

FEATURES:
- Preformed aluminum housing and door frame.  Housing is black polyester powder paint finish standard.  Also available in white, dark bronze and custom color finish.
- Rubber gasket included to prevent dirt or moisture from outside.
- Anodized aluminum reflector with high efficiency, heat and impact resistant tempered clear glass lens.

MOUNTING:
- Provided aluminum arm for square pole mounting.  Wall mount bracket available.

LAMP:
- Induction lamp have rectangular shape lamp and long lamp life rated 100,000 hours, nominal 82Lm/W, 80+ CRI.
- Lamp included.

ELECTRICAL:
- High power factor, instant start, high frequency energy, from the electronic ballast (generator); High-frequency power to the discharge vessel (lamp) to initiate and maintain a gas discharge for a rated 100,000 hours of life.
- Low start-up temperature, closed fixture for ambient temperatures range is from -25 °C to 50 °C; Higher ambient temperatures may reduce lamp life.
- Input voltage: 120-277V
- Input frequency: 50/60Hz

LISTING:
- UL/CUL pending.
- Suitable for wet location.
- Limited 10 years warranty on induction system (including material & workmanship).
- ARRA compliant. (optional)
